THE LED MINI™ 10 WATT SERIES - Indoor

General Lighting, Indirect Accent Decor Lighting, Cabinet Lighting, Stair Lighting, Floor Lighting, Commercial Lighting Applications, Restaurant Lighting and Home Theater Lighting.

WHITE (WW/CW) SPECIFICATIONS

• Color Temperature: Warm White (3500) and Cool White (5000)
• Construction: Die Cast Powder Coated Aluminum
• Lamp Life: 50,000 Hours
• Optics: Luminous Flux @700mA: Typical 680 Unit - lm
• Forward Voltage @700mA: Warm White - 14V / Cool White - 14V
• Operating Current: 700mA
• Power Consumption: 10 watts
• Control System: Standalone or DMX Controller - sold seperately
• Weight: 0.07lbs (0.03kg)
• Dimensions: L1” H 1” 2”
• Operational Environment: -40°C - 150°C
• Listings: UL pending
• Ratings: Indoor
• Warranty: 1 Year

RGB SPECIFICATIONS

• Color Temperature: Color Changing RGB
• Construction: Die Cast Powder Coated Aluminum
• Lumen Output: pending
• Lamp Life: 50,000 Hours
• Optics: 700mA Red - 87 /Green - 120 / Blue - 32 / Unit - lm
• Dominate Wavelength: Red - 625 /Green - 523 / Blue - 460 / Unit - lm
• Forward Voltage @700mA: Red - 2.4 /Green - 3.9 / Blue - 3.5 / Unit - V
• Operating Current: 700mA / Constant current
• Power Consumption: 10 watts
• Control System: Standalone or DMX Controller - sold seperately
• Weight: 0.07lbs (0.03kg)
• Dimensions: L1” H 1” R2”
• Operational Environment: -40°C - 150°C
• Listings: UL pending
• Ratings: Indoor
• Warranty: 1 Year

DOWNLOAD PDF



---

THE LED MINI2™ 10 WATT SERIES - IP68

The LED Mini is a marker light featuring a luminous surface with uniform brightness. A 1,3, and 10 W version are available, suitable for directional applications requiring a beam of light. Constructed from 316 marine grade stainless steel, the luminaire features a polished finish for enhanced appearance and corrosion protection.

Application: General Lighting, outdoor lighting, Indirect Accent Decor Lighting, Cabinet Lighting, Stair Lighting, Floor Lighting, Commercial Lighting Applications, Restaurant Lighting and Home Theater Lighting.

WHITE (WW/CW) SPECIFICATIONS

• Color Temperature: Cool White 5500 / Warm White 3100
• Construction: 316 Marine Grade Stainless Steel
• Lamp Life: 50,000 Hours
• Optics: 700mA CW-680 / WW - 500 / Unit - lm
• Dominate Wavelength: CW - 680 / WW - 556 / Unit - lm
• Forward Voltage @700mA: CW -14.0 / WW - 16.64 / Unit - V
• Operating Current: 700mA / Constant current
• Power: 10 watts, 3 watts and 1 watts
• Control System: Standalone
• Weight: **0.07lbs (0.03kg)
• Dimensions: L1” H 1” R2”
• Operational Environment: -40°C - 150°C
• Listings: ETL - Suitable for wet areas
• Ratings: IP68
• Warranty: 1 Year
• Installation Types: 1. Pre-Installation - Concrete pour, drive-over etc.
• Installation Types: 2. Direct Burial - Landscapes, planters, etc.

RGB SPECIFICATIONS

Color Temperature: Color Changing RGB
Construction: 316 Marine Grade Stainless Steel
Lamp Life: 50,000 Hours
Optics: 700mA Red - 87 /Green - 120
Blue - 32 / Unit - lm
Wavelength: Red - 625 /Green - 523 / Blue - 460
Operating Current: 700mA / Constant current
Power: 10 watts, 3 watts and 1 watts
Control System: Standalone or DMX Controller
Weight: 0.07lbs (0.03kg)
Dimensions: L1” H 1” R2”
Operational Environment: -40°C - 150°C
Listings: ETL - Suitable for wet areas
Ratings: IP68
Warranty: 1 Year
Installation Types: 1. Pre-Installation
Concrete pour, drive-over etc.
2. Direct Burial
Landscapes, planters, etc.
