IMP-5000-DIS RGB+M ILLUMINATOR The IMP-5000 DIS-4 Series LED Light Source is a 4-channel DMX illuminator. 3 Channels for RGB and 1 Channel for Animation Motor (5th channel for amber or white optional) . This light source can be used as a standalone or can be prgrammable using DMX 512.
HIGH CONTROL RESOLUTION
The IMP-5000 DIS Series LED Light Source supports a 16-bit control resolution per output channel for accurate dimming and fine color mixing.
LOW EMI
Slow-rate controlled dimming and shielded conductors keep the driver’s EMI emissions at a very low level.
ANIMATION
IMP-5000 DIS Series LED Light Source has a 10rpm (top speed) DC motor than can be speed controlled via DMX with an attached sparkle wheel.
ROBUST THERMAL MANAGEMENT
The Impact Lighting Inc. Sync® module creates turbulent, pulsated air-jets that can be directed precisely to locations where thermal management is needed. The vortex-dominated SynJet flow enhances small-scale mixing near the heated surfaces to yield higher effective heat transfer at low-volume flow rates compared to conventional air movers. The SynJet flow is created using a patented actuator technology and proprietary fluidic packaging expertise.
FEATURES
• USITT DMX512A- and IMP-5000 Sync-compatible
ADVANTAGES
• Accurate, smooth dimming and high-res colour mixing
• Drive, control and thermal protection per fixture
• Easy network
IMP-8000 ILLUMINATOR - WHITE ONLY The IMP-8000 Series LED Light Source comes up to 5-channel DMX illuminator. 4 Channels for white and 1 Channel for Animation Motor. This light source can be used as a standalone or can be programmable using DMX 512.
HIGH CONTROL RESOLUTION
The IMP-8000 LED Light Source supports a 16-bit control resolution per output channel for accurate dimming and fine color mixing.
LOW EMI - Electromagnetic interference
Slow-rate controlled dimming and shielded conductors keep the driver’s EMI emissions at a very low level.
ANIMATION
IMP-8000 DIS Series LED Light Source has a 10rpm (top speed) DC motor than can be speed controlled via DMX with an attached sparkle wheel optional.
ROBUST THERMAL MANAGEMENT
The Impact Lighting Inc. Sync® module creates turbulent, pulsated air-jets that can be directed precisely to locations where thermal management is needed. The vortex-dominated SynJet flow enhances small-scale mixing near the heated surfaces to yield higher effective heat transfer at low-volume flow rates compared to conventional air movers. The SynJet flow is created using a patented actuator technology and proprietary fluidic packaging expertise.
FEATURES
• USITT (United States Institute for Theatre Technology) DMX512A- and IMP-8000 Sync-compatible
ADVANTAGES
• Accurate, smooth dimming and high-res colour mixing
• Drive, control and thermal protection per fixture
• Easy network setup
• Low EMI
The FUSION™ display differs from the FUSION™ (pro) in that it does not require a PC or the FUSION™ PC software: a userfriendly interface consisting of a rotary knob and LCD display allows you to access, view and change configuration parameters for your driver/controller.
The standard parameters available on the FUSION™ display include network start address, network resolution, fixture length and show. For project-based LED driver orders, you can have the parameters of your choice uploaded to the FUSION™display.
To change the LED driver configuration with the FUSION™ display, connect the FUSION™ display to the driver/controller with the UTP network cable. The FUSION™ display switches on automatically and displays the first main menu option. Turning the knob lets you browse the main menu options, pressing the knob activates the selected menu. When you enter a menu, you can browse the possible values by turning the knob, and change the value by pressing the knob once you have arrived at the value of your choice.
