THESE MADE TO ORDER FIXTURES MAKE IT EASY TO ACHIEVE LINEAR LIGHTING EFFECTS WITH CUSTOMIZED DIMENSIONS AND LIGHT INTENSITIES.

Protect precious artifacts and make jewelry sparkle with IMPACT LIGHTING INC. Optibar LightBars. These made to order fixtures make it easy to achieve linear lighting effects for display cases and many other applications with customized dimensions and light intensities required for the project. For new designs or retrofits, LightBars can be made to the exact specifications needed.

OPTIBAR LIGHTBAR
Isometric Key: B Base Size L Lit Length S Fiber Spacing/Intensity T Tail LengthB	Primary Material: Aluminum extrusion Beam Spread: 60° Fiber Type: 0.75mm PMMA Fiber Fiber Tail: 10’, 20’ or 30’ Custom lengths available Finishes: Clear or black anodized Max Exp Rating: Indoor or outdoor use Please specify with order Linking: Soft links available for longer lengths and sharp corners Mounting: Use LB-MB Mounting bracket
OPTIBAR LIGHT POINTS
Isometric Key: B Base Size L Lit Length S Fiber Spacing/Intensity T Tail LengthB	Primary Material: Aluminum extrusion Beam Spread: 60°; 40° soft or hard edge Lens Adapter available Fiber Type : 0.75mm PMMA Fiber in light bar 25 x 0.50mm in each Focal Point Fiber Tail: 10’, 20’ or 30’ Custom lengths available Finishes: Clear or black anodized Max Exp Rating: Indoor use only Linking: Soft links available for longer lengths and sharp corners
OPTIBAR LIGHT FRAME
Isometric Key: B Base size L Lit Length S Fiber Spacing (0.25”, 0.5”, & 1”)T Tail Length P Panel thicknessB	Primary Material: Aluminum extrusion Beam Spread: 60° until entering Panel, internally reflected Fiber Type: 0.75mm PMMA Fiber Fiber Tail: 10’, 20’ or 30’, Custom lengths available Finishes: Clear or black anodized Max Exp Rating: Indoor or outdoor use. Please specify with order Linking: Soft links available for longer lengths and sharp corners Panel: Panel must be monolithic, acrylic, or high-clarity glass (not laminated, float glass, etc) and surface etched no more than 25%. Light penetration is generally 12”–24” Mounting: Use LB-MB Mounting bracket (pg 104). LightFrame is not weight bearing; it should not support panel. Adhere to panel with clear silicone
