PRODUCT INFORMATION

IL2224
MINIATURE SPOTLIGHT
image Max Overall Dimensions: 1.496” (H) x 1.575” (L) (38mm x 40mm)
Trim / Flange Dimensions: 0.512” (OD) x 0.984” (L) (13mm x 25mm)
Aperture Diameter: 0.512” (13mm)
Rough-in / Cut out: Surface mount
Primary Material: Aluminum
Beam Angle: 48 (min.) – 48 (max.)
Fiber Type: Recommended ILPT 12-75
Rotation: 360
Max Tilt Angle: + / - 30°
Finishes: Black, Silver
Ferrule Requirement: 8mm or 10mm threaded ferrule
Mounting: Mounting screws to surface

IL2385
FRAMING SPOTLIGHT
image Max Overall Dimensions: 4.331” (OD) 4.094” (H) (110mm x 104mm)
Trim / Flange Dimensions: 1.969” (OD) x 4.094” (H) (50mm x 104mm)
Aperture Diameter: 1.063” (27mm)
Rough-in / Cut out: Surface mount
Primary Material: Anodized aluminum alloy
Lens Type: 27mm Clear glass lens
Fiber Type: Recommended ILPT 50-75
Rotation: 360°
Max Tilt Angle: + / - 30°
Finishes: Black
Ferrule Requirement: Special ferrule required
Mounting: Mounting screws to surface lengths and sharp corners
Mounting: Use LB-MB Mounting bracket
Mounting: Use LB-MB Mounting bracket

IL061001253
CASELIGHT, NO GLARE FLOODLIGHT, WITHOUT LENS
image Max Overall Dimensions: 1.732” OD x 0.984” H (44mm x 25mm)
Trim / Flange Dimensions: 1.732” OD x 0.079” H (44mm x 2mm)
Aperture Diameter: 0.315” OD (8mm)
Rough-in / Cut out: 1.457” (37mm)
Recess: 0.689” (17mm)
Primary Material: Aluminum
Lens Type: Clear lens
Beam Angle: 48 (min.) – 60 (max.)
Fiber Type: Recommended ILPT 12-62
Rotation: 360°
Max Tilt Angle: +/- 32
Finishes: Black anodized
Ferrule Requirement: 8mm ferrule
Mounting: Mounting nut included234.14450.617.32124435.8217.544
