gallerytech






PRODUCT INFORMATION

IL2501
FIXED LENS DOWNLIGHT
image Max Overall Dimensions: 1.969” (OD) x 1.535” (H) (50mm x 39mm)
Trim / Flange Dimensions: 1.969” (OD) x 0.157” (H) (50mm x 4mm)
Aperture Diameter: 1.063” (27mm)
Rough-in / Cut out: 1.575” (40mm)
Recess: 1.378” (35mm) excluding fiber
Primary Material: Metal
Lens Type: Beveled glass lens
Beam Angle: 15 (min) – 25 (max)
Fiber Type: Recommended ILPT 12-75
Finishes: Black, White, Gold, Silver
Ferrule Requirement: 8mm or 10mm ferrule required
Mounting: Spring clips included

IL2502
LENSED DOWNLIGHT, CLEAR OR FROSTED LENS
image Max Overall Dimensions: 1.969” (OD) x 1.535” (H) (50mm x 39mm)
Trim / Flange Dimensions: 1.969” (OD) x 0.157” (H) (50mm x 4mm)
Aperture Diameter: 1.063” (27mm)
Rough-in / Cut out: 1.575” (40mm)
Recess: 1.378” (35mm) excluding fiber flange
Primary Material: Metal
Lens Type: Clear or frosted glass lens
Beam Angle: 48°
Fiber Type: Recommended ILPT 12-75
Finishes: Black, White, Gold, Silver
Ferrule Requirement: 8mm or 10mm ferrule
Mounting: Spring clips included

IL06100822
SWIVEL FLOODLIGHT WITH LENS
image Max Overall Dimensions: 0.984” (OD) x 1.772” (H) (25mm x 45mm)
Aperture Diameter: 0.748” (OD) (19mm)
Rough-in / Cut out: Surface mount
Primary Material: Stainless Steel, V2A
Lens Type: Beveled glass lens
Beam Angle: 15 (min.) – 35 (max.)
Fiber Type: Recommended ILPT 12-62
Rotation: 270°
Max Tilt Angle: +/- 90°
Finishes: Stainless Steel
Ferrule Requirement: 8mm or 10mm ferrule
Mounting: Screw through yoke

IL2508
FLEX-ARM
image Max Overall Dimensions: 1.969” (OD) 3.858” (H) (50mm x 98mm)
plus length of the arm
Tube Diameter: 0.335” (8.5mm)
Drop below ceiling: 6.299” (160mm) vertical max.
Rough-in / Cut out: 1.575” (40mm)
Recess: 1.378” (35mm) excluding fiber
Primary Material: Aluminum, Steel Arm
Lens Type: Clear glass (60°) or lens (15-35°)
Fiber Type: Recommended FSPT 25
Finishes: Black, White, Gold, Silver
Ferrule Requirement: Special ferrule required
Mounting: Spring clips included
Note: Consult factory for custom length

icon
DOWNLOAD PDF
