INDUCTION CIRCLINE RETROFIT KIT 5.5” STEM
• Ideal replacement lamp for Metal Halide or High Pressure Sodium indoor or outdoor light fixtures with Mogul (E40) base. (Medium E26 base optional)
• Bright White light (5000 K) for greater visibility and safety
• High Quality
• Glare Free light with CRI above 83
• Electronic Ballasts made with long life components
• InstantON(TM) flicker-free Cold Start and Hot Re-Start
• High Power Factor, Low THD Ballast technology
• Advanced phosphors for high lumen maintenance and high lumen output
• Optional : 4100°K, 6500°K
• Universal Mounting Positions: Base up, Base down, Horizontal
• Made with Amalgam Technology
SPECIFICATION
• Ballast Type: Electronic
• Start Method: InstantON
• Hot Re-start: InstantON
• Universal Input Line Voltage: 120-277 VAC
• Input Line Frequency: 50/60 Hz
• Lamp Life: 100,000 Hrs.
• Lumen Maintenance @75,000Hrs: >70%
• Color Temperature: 5000 K
• Color Rendering Index (CRI): 83
• Minimum Starting Temperature: -20 F
• Maximum Operating Temperature: 160 F
• Lamp Operating Frequency: 250 kHz
• Power Factor: > 0.98
• Total Harmonic Distortion: < 10%
• Inrush Current Peak: < 10 Amp
• ETL Listed / UL Standard 1598: Yes
• FCC Compliance: Part 18, Subp. C
